SIP Star Twin Rotor Rakes
SIP
SIP Star Twin Rotor Rakes
The SIP Twin Rotor hydraulic folding rakes have all the features to accomplish the best centre swath and lay the platform for a good bale to suit the serious farmers & contractors.
With 4 spring tines per arm, tandem axles and height adjustable rotors the SIP double rotor rakes ensure shorter working time and greater productivity. The stability of SIP rakes facilitates efficiency and an airy and quick drying swath including on uneven terrain.
SIP Twin Swather rakes are available in the following models: R670, R770, 850, R870, R930 and 1000 – (6m – 10m widths)
Building on the success of their early Star models, SIP has recently released a number of new models (R670, R770, R870 & R930). Check out the video from Scott Malcolm (SIP Product Specialist) below where he gives an overview of these new SIP Star R series of swathers:
For more information on the range of SIP Star Swathers, please get in contact with:
Winston Smith
SIP Product Specialist (North Island)
Scott Malcolm (South Island)
SIP Product Specialist (South Island)
Specifications
| Model | Star R670 T | 22 | Star R770 T | 24 | Star 850/26 T | Star R870 | 26 | Star R930 | 28 | Star 1000/30 T |
|---|---|---|---|---|---|---|
| Working Width | 5.8 – 6.7m | 6.8 – 7.70m | 7.24 – 8.30m | 7.60 – 8.6m | 8.2 – 9.3m | 8.82 – 9.94m |
| Number of Rotors | 2 | 2 | 2 | 2 | 2 | 2 |
| Swath Width | 1.10 – 2.30m | 1.2 – 2.10m | 1.15 – 2.10m | 1.3 – 2.2m | 1.3 – 2.4m | 1.38 – 2.50m |
| No Tine Arms/Rotor | 11 | 12 | 13 | 13 | 14 | 15 |
| Weight | 1740kg | 2040kg | 2040kg | 2600kg | 2800kg | 2750kg |
Features & Benefits
Modular Rotor
Each arm and parts are easily detachable giving easier maintenance in the event something breaks. The large hardened and tempered cam track lowers wear and tear on cam bearings as well as cam track and with a diameter of 420mm, the SIP cam track is one of the largest available on the market.
Adjustable Cam Track
All SIP Swather rakes come standard with an adjustable cam track. This gives the operator the chance to make the optimum swath shape according to the grass conditions.
3D Rotor Pivot
Multiway pivoting enables great contour following in all working, even when the going gets steep.
Hydraulic Width Adjustment
The working width is easily adjustable from the tractor cab using hydraulics.* Model Specific
Transport Locking
When rotors are put into the transport position, they are locked into position, stopping them from swaying around when travelling on roads, which reduces wear and tear costs.* Model specific
Walking Tandem Axle
A walking tandem axle allows the rake to follow the ground up to 50% more evenly and smoothly in comparison to the standard tandem axle.
