SIP Star Four Rotor Rakes
SIP
SIP Star Four Rotor Rakes
The new design four-rotor rake is equipped with hydro-pneumatic suspension of rotors and SIP patented triple walking tandem axle and enables up to 12.50m working width. 9.90m – 12.50m working widths
- 4 rotor
- Adjustable cam track
- 3D pivoting rotors
- Hydraulic width adjustment
The new design four-rotor swather completes an exceptional line up to the family of SIP rakes. With hydro-pneumatic suspension of the rotors combined with triple SIP patented walking tandem axles, this provides superior ground contouring and the perfect row.
For more information on the SIP Star 1250 Swather, please get in contact with:
Winston Smith
SIP Product Specialist (North Island)
Scott Malcolm (South Island)
SIP Product Specialist (South Island)
Specifications
| Model | Star 1250/50 T |
|---|---|
| Working Width | 9.90 – 12.50m |
| Number of Rotors | 4 |
| Swath Width | 1.30 – 2.20m |
| No Tine Arms/Rotor | 2×12/2×13 |
| Weight | 5155kg |
Features & Benefits
Modular Rotor
Each arm and parts are easily detachable giving easier maintenance in the event something breaks. The large hardened and tempered cam track lowers wear and tear on cam bearings as well as cam track.
Adjustable Cam Track
All SIP Swather rakes come standard with an adjustable cam track. This gives the operator the chance to make the optimum swath shape according to the grass conditions.
3D Rotor Pivot
Multiway pivoting enables great contour following in all working, even when the going gets steep.
Hydraulic Width Adjustment
The working width is easily adjustable from the tractor cab using hydraulics.
Transport Locking
When rotors are put into the transport position, they are locked into position, stopping them from swaying around when travelling on roads, which reduces wear and tear costs.
Walking Tandem Axle
A walking tandem axle allows the rake to follow the ground up to 50% more evenly and smoothly in comparison to the standard tandem axle.
